Hot Air Furnace
| Model/Parameter | Output Heat (KJ/h) | Output Air Volume (m3/h) | Output Temperature (℃) | Oil Consumption (kg/h) | Burner Model |
| ZDQR1 | 1.0×106 | 5400 | 60-350 | - | - |
| RLY-2.5 | 1.045×105 | 1500-560 | 60-200 | 4-5 | M4 |
| RLY-4 | 1.672×105 | 3500-930 | 60-200 | 6-7 | M8 |
| RLY-8 | 3.344×105 | 5600-1480 | 60-200 | 11.5-13.5 | M12 |
| RLY-15 | 6.270×105 | 12000-2160 | 60-250 | 21.5-25 | M20 |
| RLY-30 | 12.54×105 | 25000-4330 | 60-250 | 43-50 | MP35AB |
| RLY-40 | 16.72×105 | 28000-5600 | 60-250 | 57-67 | MP45AB |
| RLY-60 | 25.08×105 | 45000-8660 | 60-250 | 86-100 | MP80AB |
| RLYL-80 | 33.44×105 | 83000-12500 | 60-350 | 114-135 | MP130AB |
| RLY-160 | 66.88×105 | 134400-23000 | 60-350 | 228-270 | MP200AB |
| RLY-200 | 83.60×105 | 170000-28000 | 60-350 | 286-334 | MP300AB |
Note:
- The above parameters are for reference only, subject to actual operating conditions
